Code: 01:10 Description:Electronics Module failure.The possible cause could be: 1. The Electronics Module is of the wrong type (a 16 MB Electronics Module will not work in a 24" Model). 2. Reading, writing or initializing the EEROM failed. 3. One of the ASIC’s was not found within the Serial Bus that connects the Electronics Module to the Carriage Assembly. 4. One of the ASIC’s did not respond to the Serial Bus that connects the Electronics Module to the Carriage Assembly. 5. The Electronics Module is requesting a move to the Service Station while the previous move is still being completed. 6....

If your HP DesignJet model 500 or 800 won't communicate with your Windows 11 (or Windows 10) computer, don't worry --there is a solution! A very helpful customer clued us in on getting the PC to talk to the printer:  "Below is the HP Support page showing the driver choices (note that I selected Windows 8.0. I chose "HP DesignJet 500 PCL3GUI 64-bit" for my HP Designjet 500 42-inch and downloaded zipped file hpdj500wx64pclen which I then unzipped to a folder on my C: drive. I then went into Windows Setup, connected the plotter to a usb port, turned the plotter on,...

Using the Power Switch LED to Troubleshoot In certain circumstances the LED located in the power switch can help to troubleshoot the Printer. The LED can be OFF, ON or flashing and using different combinations can indicate different problems. NOTE: You should only use the LED to troubleshoot when the Printer does not Power up completely. The LED may flash in other circumstances which are completely normal and this does not mean that there is a problem with the Printer. LED is OFF - This indicates that the Power Supply Unit is completely dead. Try the following: 1. Check that power cord is connected correctly to the...

Recently we changed the belt on a hp 500 designjet and although the belt was installed correctly using as a guide your video, the plotter keeps trying align the print heads in a loop cycle. we've tried everything. we read on a forum that the carriage has two bushes that if installed upside down could cause this but we didn't see any bushes on the carriage. any thoughts? Thanks in advance. The print heads were removed for the belt replacement and probably dried up.  Try removing the print heads blast them at short range with Windex 5-10 times and then...

I purchased your belt replacement kit for an HP DesignJet 800 and performed the job per your great video. The plotter got about 90+% complete printing the test plot on the gloss paper(image attached).  The plotter did not cut the paper.  Then it showed Error 86:01. I reviewed the job, your video and other videos trying to help with this error code.  Things I’ve done. Lubricated the drive rod Removed and cleaned the cutter head.  Its seems to move ok, but I don’t know how much resistance should be when sliding this part. The bushing moves smooth on the rod,...
