Designjet T & Z Series Paper Motion Motor with Media Advance Transmission
Designjet T & Z Series Paper Motion Motor with Media Advance Transmission and Roller Encoder Sensor (Select version appropriate to your machine)
Condition: Refurbished, Live-tested
Warranty: 12 months
The replacement procedure for this part is found in section 6-180 of the service manual --available here.
CH538-67027, Q5669-60700, Q5669-60704, Q6683-50009, CH538-50003
Media motor and transmission WITHOUT drive roller sensor and disc for advancing the media. There are 3 variants of this part. Please select from the drop-down box the variant that fits your printer. This assembly fits the following printers:
|
|
|
|
|
|
|
|
|
|
|
Errors related to the media-axis motor:
- Error 41:03
- Error 41:YZ
- Error 41.1:YZ
- Error 81:01
- Error 85:01
IMPORTANT: On T770, T1200, T1300, T2300, and newer machines, there is an ID chip embedded on the drive roller encoder sensor. The machine's ID chip is paired to the HDD, so if you replace the encoder sensor, KEEP YOUR OLD ONE. You can plug the ID cable into the ID chip on your old encoder sensor, while the power/sensor cables are plugged into the replacement sensor.
Designjet T & Z Series Media Advance Motor and Transmission
Q5669-60005
